Performa Logix Demand Control Mineral Tank w/Basket Distributor
ITEM SPECIFICATIONS 32,000 - 110,000 Grains
AUTOTROL 263 & 268 RESIDENTIAL PERFORMA CONTROL VALVES FEATURES/BENEFITS
Time-tested Duraflow flapper provides frictionless sealing for longer service life Fiber-reinforced polymer valve body for superior strength and durability, non-corrosive, and UV-resistant Optical sensor for precision cycle positioning Designed with double backwash for reduced hardness leakage Fully adjustable 5 or 8 cycle control for efficient and reliable water treatment system Continuous service flow rate of 25 GPM with a backwash of 20 GPM Backwash capability accommodates softener tanks up to 16" and filter up to 18" in diameter
Super capacitor for keeping time of day during power outage Environmental protective cover for water resistance, corrosion resistance, and UV stability Soft water refill for a cleaner brine tank Programming stored in memory and will not be lost due to power outages History data for valve performance OPTIONS
Filter or softener control valves Fiber-reinforced polymer bypass valve Plumbing connections in .75"-1.25" NPT, BSP, and sweat Internal Autotrol turbine Variable reserve for increased efficiency Auxiliary switch kits Timer wall mount kits 740- Simple economic electronic time clock control. 764- Professional level metered control with fully programmable cycle times and salt amount for multiple tank applications. 760- Simple economic electronic meter control.
742- Professional level time clock control with fully programmable cycle times and salt amount. 762- Professional level metered control with fully programmable cycle times and salt amount. 460i - 3 settings for metered control 460TC - 3 settings for time clock control TESTED and CERTIFIED by the WQA to NFS/ANSI Standard 44 for Water Softener Performance.
TESTED and CERTIFIED by the WQA to NFS/ANSI Standard 372 for Lead Free Compliance. Restriction of Hazardous Substance Compliant
VALVE SPECIFICATIONS Valve Body Glass-filled thermoplastic Rubber Components Compounded for cold water Weight (Valve & Control) 5.3 lbs (2.4 kg) Operating Pressure 20-120 psi (1.38-8.27 bar) Canada: 20-100 psi (1.38-6.89 bar) Hydrostatic Test Pressure 300 psi (20.69) Water Temperature 35°-100°F (2°-38°C) Ambient Temperature 35°-120°F (2°-48.9°C) *Recommend use of outdoor cover for direct sunlight applications
ELECTRICAL Controller Operating Voltage 12 volt– AC Input Supply Frequency 50 or 60 Hz Moter Input Voltage 12 volt– AC Controller System Power Consumption 3 watts average TRANSFORMER- ALL CONTROLLERS Transformer Output Voltage 12 volt– AC 400mA Transformer Input Options 115 volt– AC 50/60 Hz 230 volt– AC 50/60 Hz 100 volt– AC 50/60 Hz Transformer Plug Options Indoor North American Plug Outdoor North American Plug Japanese Plug Taiwan/Korea Plug Australian Plug United Kingdown Plug Mainland Europe Plug VALVE CONNECTIONS Tank Thread 2-1/2" – 8, male Inlet/Outlet Threads 1-3/4"-12 UNC-2A male Drain Line 3/3" NPT, male Brine Line 3/8" NPT, male DIMENSIONS Width 14.9" (37.8 cm) Height 8.5" (21.5 cm) Riser Tube Dia. 1.050" (27 mm) Riser Height Above top of tank 0.5" (+/- 0.5") FLOW RATE Service 15 psi (1.03 bar) drop 25.0 gpm (5.7 m3 /h) Backwash 25psi (1.72 Bar) drop 20.0 gpm (4.5 m3 /h) Service Cv = 6.50 (Kv = 5.6) Backwash Cv = 4.00 (Kv = 3.5) WATER QUALITY SYSTEMS 5730 NORTH GLEN PARK ROAD, MILWAUKEE, WI 53209 P: 262.238.4400 |
